NavVis IVION Core Product Brochure

Efficiently process, register, publish, and deliver your scan data online
Inspect, plan and measure with a building visualization that’s easy to navigate
Improve efficiency by giving your team and clients access to the full point cloud data from anywhere

Optimize scan-to-BIM workflows and boost verification efficiency
Go beyond modeling and offer your clients even more value with a new kind of deliverable that extends the use of 3D scan data

Product features

Maps and custom floorplans

Give your customers an entirely new way to use and interact with floorplans. NavVis IVION Core automatically generates an AI-based map to give an overview of the entire site. Upload custom maps that have been designed in photo editing software.

Mark & Measure

360° immersive images are not just digital images. The pixels in these images are enriched by laser scans, which makes it possible to interact with scanned spaces as if you were on site. Conveniently take, organize in folders, and share point-to-point measurements with Mark & Measure. Display exact coordinate information and take point and orthogonal measurements for further precision.

Site coordinate system

Enter the latitude and longitude or a custom spatial reference system, allowing for survey-grade georegistration of data. Selecting your own site coordinate system also ensures that your data is aligned to the exact location of your site, making it easier and faster to upload and download data.

Multiple sites

Access all of your projects from one account. Easily switch between and search for sites from a central dashboard. Each site has a unique website address and user permissions giving you complete control over site usage.

Publish and share online

Using a web browser, NavVis IVION Core simplifies publishing and sharing scan data. Just send a link to publish and share scans or send a deep link to specific content or a location within the scan. No downloads, plug-ins or desktop software required.

All your scans in one place

Whether you’re using static laser scanners, drones or NavVis VLX, you can upload and combine datasets in NavVis IVION Core and publish the scans as a link. For structured E57 files, you can automatically convert point clouds into immersive 360° images with full NavVis IVION Core functionality.

Points of interest

NavVis IVION Core features an easy to use, scalable content management system for adding geo-tagged information and media to 3D scans. Users can rightclick anywhere on the screen to add and view this information as points of interest. The powerful search function makes it easy for users to find the information they need.

Crop and download point clouds

NavVis IVION Core allows users to download sections of a point cloud in different file formats, so you can edit your point clouds and import them into other software programs. Make a selection in the point cloud with the 3D crop box to only download what you need.

Align and register scans

Align and register of all your NavVis scans as well as scans from third party devices. This feature includes the ability to perform automatic cloud to cloud alignment.

Quality Control Visually

inspect point clouds using multiple 2D views and slices of the the 3D scene. These interactive views provide users with the ability to assess the quality of the point cloud and identify incorrect registrations.

Swap old datasets with new

Thanks to the advanced data management capabilities within NavVis IVION Core, exchanging outdated data with new data has never been easier. This ensures users will always have access to the most up-to-date and reliable spatial data.

Data workflow management

Streamline operations by enabling users to work simultaneously within the same site. Data admins can seamlessly manage and update new data, while at the same time, end users can continue working using the most recently published version. This simplified workflow centralizes data management without disrupting end users.

For laser scanning professionals

Set up a virtual site

Automatically generate multiple cloud-based sitesfor your projects — all in one space.

Upload point clouds

Add data to NavVis IVION Core by uploading point cloud files captured by NavVis systems or simply upload any structured e57 file.

Geo-register scan data

Enter the coordinates or address of each file that has been uploaded to register the scan data to the correct coordinates on the world map.

Merge multiple scans

Merge multiple scans by placing datasets at the correct coordinates relative to one another using the dataset alignment tool.

Structure building models

Structure data into basic building models by defining the rooms, floors and work spaces.

Publish online

Publish and share your 3D buildings as a web-based URL. You can give stakeholders access to the entire instance, individual sites or even just one building within the site.

Product details

Best for

Surveying and Reality Capture
Architecture, Engineering and Construction
Process and Plant

Size in sqm

Less than 200.000

Registered users

Viewers

Unlimited

Numbers of sites

Unlimited

Cloud infrastructure

Multi-tenant

Process wherever and whenever

Start, monitor, and finish processing tasks on your own terms, and reduce the time from mapping to usable data.

Efficiency where it matters

Process multiple datasets in parallel, and save valuable time and effort for the tasks that require individual attention.

Easy to set up and use

An uncomplicated workflow and user-friendly interface eliminate the need for extensive onboarding and additional training.

Safe & secure

State-of-the-art cloud-enabled security and storage ensure your data remains secure.

NavVis IVION Core

Add more value to buildings and assets

A reality capture platform for surveying, laser scanning, and AEC professionals. Manage your 3D scan data with intuitive tools for creation, collaboration, and publication.
