5 Alternatives to
Note: This article is authored by NavVis and was last updated on 23.02.2022.
It used to be simple to buy a laser scanner. Now, as the number of options on the market grows, the decision is becoming much more complex.
Choosing the right tool in 2022 depends on your intended application. That means you need to know: Does this device help me get my projects done faster, safer, with less expense and greater efficiency? Does it produce data that meets my needs?
To know for sure, you’ll need to compare your options carefully. That’s why we’ve compiled this list of alternatives to Leica BLK2GO. We’ve done the research on five leading alternatives and outlined the important details below to help you make an educated purchase decision.
NavVis VLX is a wearable mobile mapping system designed for versatility and speed without sacrificing data quality.
The system weighs 8.7 kg and features advanced ergonomics—including a hip belt for better weight distribution—that improve operator comfort over long scans. It’s equipped with two LiDAR sensors, one on top and one in front, that capture 600,000 points per second, as well four cameras for full-coverage imagery without capturing the operator. It includes a large built-in touchscreen interface for live feedback and easy operation and hot-swappable batteries for 1.5 hours of continuous operation.
Its SLAM enables scans at up to 10 times the speed of terrestrial scanners, and has been rigorously tested to provide global accuracy of 6 mm in a testing area of 500 sq meters. This software also supports the use of ground and wall control points, which can be surveyed by total stations or GNSS and used to reduce drift, perform geo-registration, and align data sets captured by a variety of methodologies. The system also uses advanced image processing for HDR, auto-white balance, and realistic point cloud colorization.
With this image processing and the ability to scan outdoors, the system is suitable for capturing complex indoor spaces with challenging lighting, outdoor environments, and construction sites.
Good if: You want high speed and high data quality and accuracy (6 mm), comfort, the ability to scan in a variety of environments, and the ability to take on projects ranging from small to large.
The GeoSLAM Zeb Revo RT is a handheld laser scanner that offers speed and extreme portability.
Its small form factor is designed for one-handed use, weighs 1.05 kg, and includes one LiDAR sensor that captures 43,000 points per second. The device does not include a camera in its base configuration, or a display, but you can buy accessories to attach a single panoramic camera, smartphone display, GNSS, a pole, and more. You also can add a plate to the bottom of the handle which allows for the capturing of ground control points. Its battery supports four hours of continuous scanning.
This system’s SLAM enables movement in 6D, live feedback, and automatic alignment of multiple data sets. Its measured global accuracy is 6 mm. The Zeb Revo RT can bs used for the capture of both indoor and outdoor environments.
Good if: You want a mobile mapping system that prioritizes extreme portability, has a high speed of mapping, medium-to-low costs, and modularity, and your projects are small-to-medium-sized and can manage with a relative accuracy up to 6 mm.
The Trimble X7 is a terrestrial laser scanner designed to improve the speed of tripod-based LiDAR and offer easier adoption for those comfortable with traditional methods.
The system weighs 5.8 kg including battery and features a variety of advanced features, including automatic calibration, calibration reports, survey-grade self-leveling, an assistant for on-site registration, and laser-pointer-based georeferencing. The tablet or PC-based software offers direct access to configuration during scanning, as well as visual feedback on scan progress.
Trimble X7 offers high-speed terrestrial capture, with a fast raw image capture of 15 images in 1 minute, (3 minutes with HDR imaging), and a measured range accuracy of 2 mm. It is also suitable for use indoors and out.
Good if: You want a terrestrial scanner that is faster than comparable terrestrial scanners and includes more advanced features, and millimeter-level accuracy is important to your project.
The Faro Focus S350 is a terrestrial laser scanner that prioritizes high accuracy.
The lightweight scanner is only 4.2 kg including battery and works with a variety of FARO software—which is not included. It features an easy-to-use Android-based interface, a remote control with a mobile application, as well as integrated GPS, compass, barometer, and inclinometer.
Focus S350 offers a scanning range of 0.6-350 m, and up to 1 million points per second. The 3D point accuracy is as follows: 2 mm at 10 meters and 3.5 mm at 25 meters, with a ranging error of +/- 1 mm. It is suitable for use in challenging scan conditions both indoors and out.
Good if: You want an easy-to-use static laser scanner, have small-scale projects, and if millimeter-level accuracy is more important to your project than the speed of data capture.
The Leica BLK360 is a terrestrial laser scanner that prioritizes visualization and greater ease of use.
The device captures 360,000 points per second and weighs only 1 kg, making transportation and set up fast and easy. The device offers a 3D point accuracy of 6 mm at 10 meters and 8 mm at 20 meters. It comes with a one-year subscription to Leica’s device-specific software and offers an iOS and Android app that is required for control of the device, Cyclone FIELD 360.
Good if: You want a low-cost, highly-portable, easy-to-use static laser scanner, have mainly small-scale projects, and prioritize ease of use.
Choosing the right laser scanner
Choosing a laser scanning device does not have to be a difficult decision. Always keep your project and accuracy requirements in mind, and the decision will become clear.
